COMMERCIAL AND INDUSTRIAL INSULATED METAL PANELS

VERSAWALL® V+

VERSATILITY MEETS PERFORMANCE

Share

Share

VERSAWALL V+

AVAILABLE IN VERTICAL PROFILE

Versawall V+ Insulated Metal Panels create an attractive and energy efficient wall where vertical applications are desired. Available in Flat, Striated and Planked profiles and up to 4” thickness to create a high-performing building envelope. Ideal for government facilities, schools or arenas. Versawall V+ panels are remarkably strong and provide outstanding protection with lengths to 37’. Icon, UL certified

THICKNESS

2″ [51mm]

2.75″ [70mm]

4″ [102mm]

THERMAL VALUES

2″ – R=16.7 (U=0.063)

2.75″ – R=23.0 (U=0.046)

4″ – R=33.5 (U= 0.034)

PANEL WIDTH

30″ [762mm]

36″ [914mm]

PANEL LENGTH

6’ [1.8m] – 21’ [6.4m] Embossed Flat – Dark Colors

6’ [1.8m] – 37’ [11.0m] Embossed Flat – Light Colors

6’ [1.8m] – 20’ [6.1m] Smooth Flat, Planked, Striated
